【Proposal to Flatboard diecutting machine manufacturer】
This is a proposal for a new zone patching method.
The pressure of a new die cutter can become unbalanced after several years of use.
For this reason, the BOBST manual suggests that users make spot sheets.
This method involves cutting sheets of thin paper (50–60 μm thick), and adding them to areas with less cutting pressure.
![](https://dieranger.com/blog/wp-content/uploads/2021/11/ゾーンパッチ1-300x82.jpg)
![](https://dieranger.com/blog/wp-content/uploads/2021/11/ゾーンパッチ1-300x82.jpg)
However, we know that it is extremely difficult to add paper to areas with less cutting pressure.
Our Press Balance System (PBS) technology is used in some 400 die cutters in Japan. We propose equipping your new die cutters with our PBS, instead of using spot sheets.
PBS film is made of the world’s toughest resin: PPS resin made by the Japanese company Toray. Each sheet of PBS film consists of ten layers of 20 μm PPS film, with a mild adhesive holding them together.
We can equip their new die cutters with PBS film before shipment, and offer customers annual maintenance, to provide customers with die cutters that consistently cut with even pressure throughout.
The details of usage are as follows:
②Divide a regular cutting plate into two layers that add up to the original thickness (for example, instead of using a 4 mm-thick plate, use two plates 1 and 3 mm thick).
First, attach a sheet of PBS film to the 1 mm-thick stainless steel plate, then place that on the 3 mm-thick cutting plate.
![](https://dieranger.com/blog/wp-content/uploads/2021/11/ゾーンパッチ2-300x108.jpg)
③ Set them together in the die cutter with the PBS film placed on top, then perform a half cut using a sandwich die with a grid pattern.
![](https://dieranger.com/blog/wp-content/uploads/2021/11/ゾーンパッチ3-300x166.jpg)
④ Remove any sections of film that have been cut.
The pink area here indicates where a cut section has been removed.
![](https://dieranger.com/blog/wp-content/uploads/2021/11/ゾーンパッチ4-300x92.jpg)
⑤When performing die cuts, sandwich this prepared PBS film between the 1-and 3 mm-thick cutting plates, with the 3 mm-thick cutting plate placed on top.
To perform annual maintenance after a year has passed, remove the PBS film from between the cutting plates, and follow the same procedure as above: place the 1 mm-thick cutting plate on top of the 3 mm-thick cutting plate, then place the PBS film on top of that, perform a half cut, and remove any sections that have been cut.
If one sheet of PBS film is not enough to fully adjust the height (i.e. if any sections are completely cut through on a single sheet of PBS film), add a new sheet of PBS film on top of the existing one.
Performing this adjustment allows customers to enjoy consistent accuracy in their cutting machines, with minimal pressure unevenness.
![](https://dieranger.com/blog/wp-content/uploads/2021/11/ゾーンパッチ5-300x142.jpg)
![](https://dieranger.com/blog/wp-content/uploads/2021/11/ゾーンパッチ5-300x142.jpg)
Another option is to allow users to purchase a sandwich die, and perform regular maintenance on their own.
